Hand chain hoist 2T - RH-4104
21130Features
-Solar and pulley design to reduce the force required for traction
-Biaxial system and two guide rollers
-Load chains are made of steel alloy with grade 80 according to ISO 3577 standard
-Top and bottom hooks made of forged steel that slowly bends due to overload to warn of overload
-Galvanized chains available in sizes of 3 and 6 meters
-Overload protection system
Description
Chain blocks, also known as chain hoists or chain pulleys, are devices specifically designed for lifting and moving heavy loads in a vertical direction. They consist of sturdy housing containing a chain, a set of pulleys, and a ratchet mechanism. Chain blocks operate by pulling the chain through the housing, causing it to wrap around the pulleys and create a mechanical advantage that allows users to lift loads with reduced effort. The ratchet mechanism ensures that the load remains securely held in place when not being lifted or lowered. Ronix RH-4104 is another one of our offerings in the chain block category that works as described and can help you deal with loads as heavy as 2T.
Specifications
| Model | RH-4104 |
| Capacity (tonnes) | 2 T |
| No. of falls | 1 |
| Load chain (mm) | 8x24 |
| Pull to lift rated load | 457 N |
| Proof load (tonnes) | 3 T |
| Hand chain (mm) | 5x25x17 |
| Standard lift (m) | 3 |
| Net Weight | 16.2 kg |
| Gross weight | 16.7 kg |
| Extra lift per weight | 2.3 kg |
Ronix RH-4104 is a 2T chain block equipped with grade 80 steel alloy that can offer a standard lift of 3m.
